Aluminum Ramps Our Biggest Earth Drill Offer Yet – In Stock & Ready for Your Job
Looking for serious torque and performance? Here is our first-ever direct discount on Heavy Duty High Torque Auger Drives – with no gimmicks, no bundles, just raw savings. It is your chance to upgrade your earth drilling capability with industry-proven power. Call Joel now to lock in your deal before 30 Sep!
Heavy-Duty Earth Drills for Demanding Applications
Our high torque auger drives are built for tough, high-demand drilling jobs. Whether you’re in construction, earthmoving, or infrastructure development, we’ve got the gear that delivers:
- Large diameter & deep auger drilling
- Hard rock drilling
- Pole and mast installations
- Foundation pile drilling
- Large diameter screw pile installations
- Rail applications
| MODEL | 70000 MAX | 80000 MAX | 100000 MAX | 150000 MAX |
|---|---|---|---|---|
 |  |  |  |
|
| Carrier Weight | 21-45t Excavator | 21-45t Excavator | 21-50t Excavator | 21-50t Excavator |
| Oil Pressure Range | 160 - 300 Bar | 160 - 280 Bar | 160 - 350 Bar (2321 - 5,076 psi) | 160 - 340 Bar (2,321 - 4,931 psi) |
| Torque Range | 38016 - 71280 Nm | 46227 - 80898 Nm | 45,746 - 100,069 Nm (33,741 - 73,807 ft-lb) | 71,680 - 152,319 Nm (52,868 - 112,344 ft-lb) |
| Oil Flow Range | 100 - 280 lpm | 100 - 280 lpm | 100 - 280 lpm (26.4 - 74.0 gpm) | 100 - 340 lpm (26.4 - 89.8 gpm) |
| Speed Range | 7 - 9 rpm | 9 - 15 rpm | 5 - 15 rpm | 4 - 12 rpm |
| Hub Options | 130mm Square 130mm Hex (optional) (Output shaft adaptors available) | 130mm Square 130mm Hex (optional) (Output shaft adaptors available) | 150mm Hex | 150mm Hex |
| Height | 1625 mm | 1625 mm | 1,623 mm (63.90in) | 1,863mm (73.35in) |
| Width | 524 mm | 524 mm | 636mm (25.04in) | 766mm (30.16in) |
| Weight | 750kg | 760kg | 1061 kg (2,339 lbs) | 1,491 kg (3,287 lbs) |
| Hitch Options | Double Pin Cradle | Double Pin Cradle | Double Pin Cradle Hitch | Double Pin Cradle Hitch |
| Valve Options | 2 Way Valve - Converts single acting hammer into a 2 way auxiliary flow. | 2 Way Valve - Converts single acting hammer into a 2 way auxiliary flow. | 2 Way Valve - Converts single acting hammer into a 2 way auxiliary flow | 2 Way Valve - Converts single acting hammer into a 2 way auxiliary flow |
Whether you’re a construction or earthmoving crew, a utility and infrastructure contractor, a rail and transport installer, or a foundation and screw pile specialist — we’ve got your back!
- Heavy-duty durability trusted worldwide
- Gear specialist engineering – over 25 years of experience
- Responsive, expert service and technical support
- Custom fabrication available – large flights, hard rock, extra-long augers? No problem!
Don’t Miss Out – 📞 Call Joel Now! Lock in your deal before 30 Sep!
